IPQ9574 – A flagship, high-performance Wi-Fi 7 SoC, designed for enterprise routers, tri-band/quad-band APs, carrier-grade CPE, and outdoor base stations.
IPQ5424 – A mid-range Wi-Fi 7 platform, aimed at cost-effective routers, residential gateways, and SMB access points.
| Feature | IPQ9574 | IPQ5424 |
|---|---|---|
| CPU | Quad-core Cortex-A73 | Quad-core Cortex-A53 |
| Clock | Up to ~2.2 GHz | Up to ~1.5 GHz |
| Performance | High performance computing, strong routing throughput, ideal for multi-gigabit scenarios | Lower power consumption, adequate for mainstream routers |
Conclusion:
IPQ9574 has significantly more processing headroom for handling multi-gigabit traffic, VPN, advanced security, and heavy AP controller workloads.
| Feature | IPQ9574 (Wi-Fi 7) | IPQ5424 (Wi-Fi 7) |
|---|---|---|
| Bands | Supports 2.4G / 5G / 6G (with external radios such as QCN9274/QCN6274) | Supports 2.4G / 5G / 6G |
| Max MIMO | 4×4 (commonly paired with QCN9274/6274) | 2×2 (mid-range radio design) |
| Bandwidth | Up to 320 MHz | Up to 320 MHz |
| QAM | 4096-QAM | 4096-QAM |
Conclusion:
Both SoCs support the latest Wi-Fi 7 features, but IPQ9574 is typically designed for higher-end 4×4 radios, making it better for long-range, high-throughput, and enterprise APs.
| Category | IPQ9574 | IPQ5424 |
|---|---|---|
| RAM | DDR5 / DDR4 | DDR4 |
| Ethernet | Up to 10G interfaces depending on board design | Typically 2.5G interfaces |
| PCIe | More PCIe lanes, suitable for multiple Wi-Fi 7 radio cards | Fewer PCIe lanes |
| Acceleration | More powerful hardware NAT, crypto, and network acceleration | Basic acceleration capabilities |
Conclusion:
IPQ9574 is built for multi-interface, multi-radio systems (tri-band/quad-band), while IPQ5424 suits simpler single/dual-band devices.
IPQ9574: Higher power consumption due to A73 cores and support for multiple 4×4 radios.
IPQ5424: Much lower power usage, suitable for home routers, compact gateways, and SMB APs.
Enterprise Wi-Fi 7 access points
Outdoor CPE/bridge devices
Multi-gigabit wireless backhaul
High-density Wi-Fi deployments
Carrier-grade routers
Residential Wi-Fi 7 routers
SMB access points
Cost-optimized gateways
Low-power industrial IoT hubs
IPQ9574 = High performance | High-end enterprise | 4x4 | Multi-gigabit | Heavy computing
IPQ5424 = Mid-range | Cost-effective | 2x2 | Lower power | Residential/SMB
If your goal is top-tier performance, long-range APs, or multi-band Wi-Fi 7 systems, IPQ9574 is the ideal choice.
If you are building a stable, cost-efficient Wi-Fi 7 product for home or SMB markets, IPQ5424 provides excellent value.
